Clopay, Modern Style, Modern Steel Collection, Residential Garage Door
Modern Steel™
Style: Residential, Modern
Whether it’s a modern makeover or a retro redo, our Modern Steel doors come in many low-maintenance styles to boost your home’s curb appeal. All are available in multiple paint colors as well as wood-look and matte finishes to match your home’s look.Overview
3-, 2- or 1-Layer Construction
Available in 3, 2 or 1-layer construction options
Design Customization
Choose from flush or grooved panel designs, each with unique texture and paint options including solid paint colors, Lustra™ matte, Ultra-Grain®, or Ultra-Grain Plank wood-look finishes. Short, long and contemporary slim windows can be stacked vertically down one side, both sides, and placed in some or all sections.
Insulation
Insulation options include 2" or 1-3/8" Intellicore® polyurethane foam, and 2", 1-3/8" or 1-5/16" polystyrene. R-values range from 6.3 to 18.4.
Door Reinforcement
WindCode® door reinforcement product available for high wind load applications.
Environmental Assurance
Clopay doors are compliant with environmental laws and regulations. Clopay doors do not contain HFCs. All Clopay doors are compliant with:
- California SB 1013
- Washington HB 1112 – Hydrofluorocarbon Greenhouse Gas Emissions
- Canadian regulations amending the ozone-depleting substances and halocarbon alternatives regulations
- New Jersey A-5583/S-3919 – Greenhouse Gas Bill
Construction
Modern Steel doors come in 3, 2, or 1-layer construction with multiple insulation choices.
- Steel
- Intellicore® Polyurethane or Polystyrene Insulation
- Steel
Intellicore® Insulation
Warmer. Quieter. Stronger.
Garage doors featuring Intellicore insulation technology represent the ultimate smart choice for homeowners. Clopay’s Intellicore is a proprietary polyurethane foam that is injected into a garage door, expanding to fill the entire structure. The result is a door with incredible strength, energy efficiency, and durability.
Additional Features
- Rust-Prevention System: Steel skins are protected with a tough, multi-layer coating system, including hot-dipped galvanizing, a protective metal oxide pretreatment, then a baked-on primer and top coat.
- Replaceable vinyl bottom weather seal in a rust-resistant aluminum retainer helps keep out air and water.
- A patented Safe-T-Bracket® prevents serious injury that could occur if the bottom bracket were removed with the garage door closed and under tension
- All Intellicore® insulated doors come standard with 10-ball nylon rollers and heavy-duty 14-gauge steel hinges.
- Product complies with 2015 IECC air infiltration requirement of 0.40 cfm/ft2 or less (IECC, Section C402.5.2)
- Window grilles are removable for easy cleaning.
Design Options
Flush Panel
Grooved Panel*
Flush With Long Windows*
Grooved with Short Windows*
Flush with full view short panel windows*
Flush panel with short windows*
Grooved with Long Panel Windows*
Full view with short panel windows*
Flush with Contemporary Slim Windows
